VRA Cloud -Add the users in Projects and Change the owner of deployment dynamically using Python abx action

Recently i came across the used case , Where daily 100+ deployments are getting submitted via Service Account with CI/CD tool Jenkins or Code stream. Later VRA admin has to change the owner of the deployment to end user manually and To change the Owner of deployment currently VRA support only for those user who are explicitly part of project . VRA Admin first add the user in project and assign the permission then he does the change owner task.

Although it is 3-5 click Job but If we have to do for 100+ user , this can become very tedious task . To ease the Job I have created the Python ABX action and Yaml which will take the input who shall we be the owner of the deployment and Will add that user in Project and assign the ownership of deployment to specified user. Below shows the flow of operation.

As we see First we need Catalog Item which accepts the above items . For that below is the Yaml reference.

formatVersion: 1
inputs:
  email:
    type: string
    title: Owner Email
    pattern: "^[a-zA-Z0-9+_.-]+@[a-zA-Z0-9]+.[a-zA-Z0-9]+$"
    description: 'Enter valid email Address exam: support@vmwarecode.com'
  role:
    type: string
    title: User Role
    enum:
      - administrator
      - member
      - viewer
  type:
    type: string
    title: User Type
    enum:
      - user
resources:
  Cloud_vSphere_Machine_1:
    type: Cloud.vSphere.Machine
    properties:
      image: Linux
      flavor: Small
      constraints:
        - tag: 'vCenter155:Cluster'
      networks:
        - network: '${resource.Cloud_vSphere_Network_1.id}'
  Cloud_vSphere_Network_1:
    type: Cloud.vSphere.Network
    properties:
      networkType: existing
      constraints:
        - tag: 'vCenter155:network'

Save the Blueprint and release it , Catalog Item will look like below.

Next step is create the Python ABX action, To do that we have some prerequisites
1. Save the VRA cloud api url in secrets by name VRAURL
2. Save CSP token with full role permission in secrets by name token.

Here is the screenshot for reference.

Once we have created above 2 secrets , we are good to go for creating Python ABX action.
Here is the code , Only thing I have hardcoded in Project ID in code in line number 11 . you may provide your project ID in code.

import requests
import json
from requests.packages.urllib3.exceptions import InsecureRequestWarning

requests.packages.urllib3.disable_warnings(InsecureRequestWarning)

def handler(context, inputs):
    vraurl = context.getSecret(inputs['VRAURL'])
    token = context.getSecret(inputs['token'])
    deploymentid = inputs['deploymentId']
    id = '4d0f75d5-8855-481b-a78d-2e5957fd8cc4'
    email = inputs['requestInputs']['email']
    role = inputs['requestInputs']['role']
    type = inputs['requestInputs']['type']
    api_version_url = f'{vraurl}/iaas/api/about'
    headers = {
        'accept': "application/json",
        'content-type': "application/json"
    }
    output = requests.get(url=api_version_url, headers=headers, verify=False)
    if output.status_code == 200:
        latest_api_version = output.json()['latestApiVersion']
        apiversion = latest_api_version
        # Getting the Bearer token

        # Getting the bearer token
        iaasUrl = f"{vraurl}/iaas/api/login?apiVersion={apiversion}"
        refreshtoken = token
        iaasPayload = f'{{"refreshToken": "{refreshtoken}"}}'
        iaasApiOutput = requests.post(iaasUrl, data=iaasPayload, headers=headers, verify=False)
        if iaasApiOutput.status_code == 200:
            print('Authentication completed with VRA Cloud')
            jsondata = iaasApiOutput.json()['token']
            bearerToken = "Bearer " + jsondata
            bearertoken = bearerToken
            headers = {
                'accept': "application/json",
                'content-type': "application/json",
                'authorization': bearertoken
            }

            # adding the New User to Project
            url = f'{vraurl}/project-service/api/projects/{id}/principals'
            payload_schema = {
                "modify": [
                    {
                        "email": "",
                        "type": "",
                        "role": ""
                    }
                ],
                "remove": [
                    {
                        "email": "",
                        "type": ""
                    }
                ]
            }
            user_inputs = {
                "email": email,
                "type": type,
                "role": role
            }
            payload_schema['modify'][0].update(user_inputs)
            apioutput2 = requests.patch(url, headers=headers, data=json.dumps(payload_schema), verify=False)
            if apioutput2.status_code == 200:
                # Changing the owner
                print(f'User {email} has been added to Project')
                url2 = f'{vraurl}/deployment/api/deployments/{deploymentid}/requests'
                data = {
                    "actionId": "Deployment.ChangeOwner",
                    "inputs": {
                        'New Owner': email
                    }
                }
                apioutput3 = requests.post(url2, headers=headers, data=json.dumps(data), verify=False)
                print(apioutput3)
            else:
                print(apioutput2)
                print(apioutput2.json())
        else:
            print(iaasApiOutput.status_code)
            print(iaasApiOutput.json())
    else:
        print(output.status_code)
        print(output.json())

Below is the Reference screenshot of Python ABX action.

Once we have created the Python Action , Last step is create the subscription.

We are using Deployment completed event here and Here is the screenshot.

All configuration is sorted , Now Once you submit the build via CI/CD or self Service , It will add the user in project with specified permission and change the deployment owner.

VRA Cloud -Python ABX action to send the VM provisioning status alerts to Slack & Microsoft teams

Recently I have written Blog for Automatic deletion and I have received multiple queries how can we notified before the deletion happens or what is the reason of failure. Previously i thought I will update failure reason in Python action.
Later I thought what if we get notification on common communicator like Slack, Teams, It would make job lot easier to keep track how many deployments were got failed or Success with Slack/Teams Notification, Also It would allow us to choose whether we want to send notification to Slack/ teams or not , If yes In which Channel we want to send the notification .

Continue reading

How to perform automatic deletion of failed deployment in VRA 8 using Python ABX action

One of the most common scenario in VRA 8 is about testing and dealing with failed deployments. when we start provisioning the vms using VRA, there will be situation when we face multiple failures due to Configuration issues or Infra side issues .

In such scenario, Deleting the failed deployment one by one can become tedious task , here is the screenshot of similar situation .

Continue reading

How to provide VM lease date during the submission of VM build in VRA8 using ABX flow

Recently I was on working on scenario where we want to provide the lease date of VM at the time of submission. It is well known feature in 7.x which we get .


In VRA 8.x we can play with lease only with Day 2 actions.

With the help of extensibility you can provide the lease time during submission and use extensibility to trigger abx flow/ workflow as day 2.

The flow looks like below .

Here is my Yaml looks like.

formatVersion: 1
inputs:
  leaseDate:
    type: string
    title: Lease Date
    format: date-time
resources:
  Cloud_Network_1:
    type: Cloud.Network
    properties:
      constraints:
        - tag: 'vsphere:network'
      networkType: existing
  Cloud_vSphere_Machine_1:
    type: Cloud.vSphere.Machine
    properties:
      image: Images
      abxaction: 'yes'
      leaseDate: '${input.leaseDate}'
      cpuCount: 1
      totalMemoryMB: 1024
      awaitIp: false
      customizeGuestOs: false
      storage:
        constraints:
          - tag: 'vsphere:ds'
      constraints:
        - tag: 'vsphere:cluster'
      networks:
        - network: '${resource.Cloud_Network_1.id}'

Here us my Catalog log request will look like.

It is simple blueprint and catalog request where I am using date-time as format in input and will be using for my ABX flow .

Here is the quick look of both abx action in flow
1. VRAtoken
2. Extend Lesse

import requests
from requests.packages.urllib3.exceptions import InsecureRequestWarning
requests.packages.urllib3.disable_warnings(InsecureRequestWarning)

def handler(context, inputs):
    vrafqdn = inputs['vrafqdn']
    username = inputs['username']
    password = inputs['password']
    refreshtokenurl = f"https://{vrafqdn}/csp/gateway/am/api/login?access_token"
    iaasUrl = f"https://{vrafqdn}/iaas/api/login"
    headers = {
        'accept': "application/json",
        'content-type': "application/json"
    }
    payload = f'{{"username":"{username}","password":"{password}"}}'
    apioutput = requests.post(refreshtokenurl, data=payload, verify=False, headers=headers)
    refreshtoken = apioutput.json()['refresh_token']
    iaasPayload = f'{{"refreshToken": "{refreshtoken}"}}'
    iaasApiOutput = requests.post(iaasUrl, data=iaasPayload, headers=headers, verify=False).json()['token']
    bearerToken = "Bearer " + iaasApiOutput
    print(bearerToken)
    outputs = {}
    outputs['vratoken'] = bearerToken
    return outputs
Here is another action of setting the lease.
import requests
import json
from requests.packages.urllib3.exceptions import InsecureRequestWarning
requests.packages.urllib3.disable_warnings(InsecureRequestWarning)

def handler(context, inputs):
    token = inputs['vratoken']
    vrafqdn = inputs['vrafqdn']
    deploymentid = inputs['deploymentId']
    print(token)
    print(deploymentid)
    leasedate = inputs['requestInputs']['leaseDate']
    url = f'https://{vrafqdn}/deployment/api/deployments/{deploymentid}/requests'
    headers = {
        'accept': "application/json",
        'content-type': "application/json",
        'authorization': token
        }
    data = {
        "actionId": "Deployment.ChangeLease",
        "inputs": {
            'Lease Expiration Date': leasedate
            }
        }
    jdata = json.dumps(data)
    apioutput = requests.post(url, headers=headers,data=jdata, verify=False)
    print(apioutput)
    print(apioutput.json())

Once we are done with creating the ABX action , we can create ABX Flow .

Here is the quick look for ABX flow

Once we are done with setting the flow , Last Part which is left is configuring the subscription.

Here is the quick look how my subscription looks like , we will be setting this on Deployment completed.

Disclaimer : My VRA lab has internet connectivity , so I can use any module online , you may need to make the action as module and zip it ,before you use as ABX action/flow . If you are using VRA Cloud then we can use as it is without any change.
Also This flow will trigger twice once ,One time failure is expected .

How to use Compute allocation & Network configure subscription to change the IP address and Rename of VM in VRA 8

As we talk about the automation in VM provisioning , One of the crucial step is to get the IP address from external source.

Recently I was working on used case where we want to provide the IP addresses at the time of submitting the provisioning.

There are multiple ways to do it in VRA and VRO . I am using VRA ABX Python action to achieve it.

Used Case: I want to submit more than one machine at time and provide the IP addresses at same time. For my example I am using 2 Machines here.

Subscription Used:

  • Compute Allocation
  • Network Configure

First Lets take a look at Blueprint’s Yaml where we define all custom properties.

formatVersion: 1
inputs:
  firstVM:
    type: string
    title: NewVMName1
  SecondVM:
    type: string
    title: NewVMName2
  VM1IP:
    type: string
    title: VM-1-IP
  VM2IP:
    title: VM-2-IP
    type: string
resources:
  vSphere_Machine:
    type: Cloud.Machine
    properties:
      firstVM: '${input.firstVM}'
      SecondVM: '${input.SecondVM}'
      VM1IP: '${input.VM1IP}'
      VM2IP: '${input.VM2IP}'
      abxaction: 'yes'
      count: 2
      image: VMwareCode-CentOS
      flavor: VMwareCode-small
      networks:
        - network: '${resource.vSphere_Network.id}'
          assignment: static
  vSphere_Network:
    type: Cloud.vSphere.Network
    properties:
      networkType: existing
      constraints:
        - tag: 'vsphere:network'

  • As we see above , I am using 4 Inputs as 2 VM names and 2 IP addresses in line 19-22
  • Line 23 we will use for condition in subscription
  • Also I am using static assignment in line 28-29
  • Line 35 is to Target the Network Profile where I have defined the Range

Once we are done with Blueprint, that is how it will look like when we click on Deploy

Since I am changing the name of VM and assigning the IP , I would need 2 ABX action
Below is the action is to change the VM Name as per Input


Below is the action Code in Python
def handler(context, inputs):
    firstVM = inputs['customProperties']['firstVM']
    secondVM = inputs['customProperties']['SecondVM']
    returnobj = inputs
    returnobj['resourceNames'][0] = firstVM
    returnobj['resourceNames'][1] = secondVM
    return returnobj

Here is the action for Assigning the IP addresses to correspond VMs.

Below is the python code for same
def handler(context, inputs):
    firstVMIP = inputs['customProperties']['VM1IP']
    SecondVMIP = inputs['customProperties']['VM2IP']
    outputs = {}
    addresses = [[]]
    outputs["addresses"] = addresses
    outputs["addresses"][0]=[str(firstVMIP)]
    outputs["addresses"].append([SecondVMIP])
    return outputs

If you have followed the article without missing any step, means you are done Python and Yaml code stuff.
Now all is left is Creation of the subscription If already not exist and Map to above created ABX python action.

To create the new Subscription follow below
Click on Cloud Assembly => Click Extensibility => Subscription = > Click New Subscription


Provide Name, enable Subscription and on Event Topic Choose Compute Allocation

If you noticed in YAML line number 23 I have specified the condition abxaction: yes

      abxaction: 'yes'

In subscription we are using that as condition to run and in action/workflow choose abx and above created action.


Click Save and we are done with Rename subscription.

Click New subscription once again and this time we will choose Network Configure subscription and network action , Rest all settings will be same.

so we have done all the coding and configuration , Now it is time to submit the VM provisioning request .

Once we submit this , You can check the outcome in action result or once vm allocation is done.


As we see the name as we submitted during provisioning, lets check the IP of each .


Both VMs got renamed and static IP which we entered has been applied to VMs.

Disclaimer: Indexing issue for multi Dimensional array has been fixed in 8.4.1, which was getting interchanged in 8.3 and 8.4

How to automate vm snapshot creation using csv and schedule automatic deletion of the snapshot using VRO 8

Snapshot is one of the great feature which we have in vSphere and which can be used like backup whenever we want to perform any change in Virtual Machine.

There are multiple ways to take the snapshot for VM using multiple products/Language.
We can use vSphere GUI or Rest APIs or pyvmomi or PowerCli .

Also as precaution when take snapshot , it is recommended to delete the snapshot after x amount of times unless we will end up in datastore full or High space utilization by vmdk .

And this is our topic of discussion of today where we automate the creation of snapshot and deletion using vro.
As we know PowerCli is great language to automate the stuff in vSphere and in VRO 8 it has been added as addtional language followed by Python.

I have used PowerCli for this workflow.

Also I have used Mime attachment as Input of CSV and Datagrid custom form element to display the existing snapshot in table.

Lets see the demo when we choose single VM from drop down

As we see once create snapshot is completed ,It will create schedule for deletion of the snapshot

For Single VM I am not checking for existing Snapshot , If you need you can take reference from multiple VM input where we are checking existing

Lets look into demo of Multiple VM’s snapshot ,where we are using CSV file as input , To process the CSV I am using Mime attachment

As you see in logs , If you specify the VM in CSV which is not in vCenter it will throw error in logs but It will not stop for other vms , If you need you can put stop on that also .

Here is the link for Package , which includes all actions and workflow related to this.

We can follow this Instruction to Import the Package

Once we are done with Import Package , Just changed the Variable value in VRO and enter your vCenter Name , UserID and Password

Here is my CSV file Sample, You do not need to have PowerState, Only thing is required is It should have name in heading

Disclaimer: We can not use this workflow as XAAS as Mime attachment is currently not supported in Service Broker for VRA8.4 .

How to utilize VRO PowerCli actions to make the VRA custom form dynamics for cluster, network and Folder in vRealize Automation 8

Recently I was working on used case where we need to make the custom form dynamics in VRA 8 . Dynamic custom forms ease the job because we do not need to hard code everything .

There are multiple ways to do this like you can use JavaScript which is being used in vro from long time

or

You can use Python and Utilize Rest API calls , Python support is added in VRA 8 design along with PowerCli.

I will be covering PowerCli language for the dynamic selection for Cluster, network and Folder

Now lets look at Yaml side configuration which is required

formatVersion: 1
inputs:
  newVMName:
    type: string
    title: NewVMName
  Cluster:
    type: string
    title: Enter Cluster
  Network:
    type: string
    title: NetworkPortGroup
  Application:
    type: string
    title: Choose Application
  Sub-Application:
    type: string
    title: Choose Sub-Application
resources:
  Cloud_vSphere_Machine_1:
    type: Cloud.vSphere.Machine
    properties:
      newVMName: '${input.newVMName}'
      abxaction: 'yes'
      image: VMwareCode-CentOS
      flavor: VMwareCode-small
      folderName: '${"VRM/" + (input.Application) + "/"+ (input.Sub-Application)}'
      constraints:
        - tag: '${input.Cluster}'
      networks:
        - network: '${resource.Cloud_vSphere_Network_1.id}'
  Cloud_vSphere_Network_1:
    type: Cloud.vSphere.Network
    properties:
      networkType: existing
      constraints:
        - tag: '${input.Network}'

As we see in highlighted row , I am taking input of 4 inputs which we will be using in custom form and I am using tags to force those values

To make the tagging work ,I have assigned same tag name as object l

Before I jump to VRO side. lets take a look how my Custom form looks like.

As you see I am getting drop down list for Enter Cluster field , To make this field Dynamic I have created VRO action and mapped to custom form.

Lets have a look PowerCli vro Action first ,Later we will see the mapping in custom form.
function Handler($context, $inputs) {
  $connection=Connect-VIServer -Server vcsa.vmwarecode.com -User administrator@vsphere.local -Password VMware123! -force
  $cluster=get-cluster|select name
  $clustername=@()
  $clustername = $cluster.name
  $as=disconnect-viserver -Server vcsa.vmwarecode.com -confirm:$False
  return $clustername
}

Either you can use the admin account or Service Account which has admin rights

Once we create action lets jump to custom form and Map the above created action .

In Custom form i chose drop down for dynamic list for Enter cluster field

In default value section I have given one of the cluster name and Value source I have set as External Source.
Since we have chosen string of array in vro and drop down in custom form , when you search for action name you will see it will reflect there

Note: com.vmwarecode/ is my Package name where I have saved all my actions, It will be different for you.

Now next task is chosen the Network Port Group based on Cluster name.

Lets have a look how does network portgroup looks like in Custom form

As you see in above screenshot , for NetworkPortGroup field the drop down is coming and those values are based on Cluster which we chose in last above step.

Lets take a look at VRO action for this one.

function Handler($context, $inputs) {
    $connection=Connect-VIServer -Server vcsa.vmwarecode.com -User administrator@vsphere.local -Password VMware123! -force
    $cluster= $inputs.clusterName
    $pg=Get-Cluster $cluster|get-vmhost|Get-VDSwitch|Get-VDPortgroup|select name
    $pgname=$pg.name
    $as=disconnect-viserver -Server vcsa.vmwarecode.com -confirm:$false
    return $pg.name

}

As we see we are taking input for the clusterName then getting the Portgroup mapped to ESXi host which are mapped to cluster.

Once vro action is configured ,Lets have a look at Custom form settings.

As we see we are using external value for this field also and mapping the VRO action nameed getVirtualPortGroup
Also we are using Canvas field and mapping with Enter cluster field from canvas.

Now next task is choose the Folder name dynamically where VM will be provisioned .

Before we start coding for Folder , lets review the current architecture of Folders in vCenter.

As we can see in above screenshot , we have Main Folder Called VRM. Under that I have 2 Sub Folder called Dev and Prod

Under Dev I have 2 more sub folders called App-dev and AppTest
Under Prod I have 2 more sub folders called App-Prod and App-Test.

If we noticed we have same sub-folder named called App-Test in Dev and Prod Folder

Now lets have a look at folders in Custom form.

Once we select for Choose Application field, we will see child folders for above selected.

Lets look at VRO actions for both fields one by one.

Lets look at choose application vro action which is named as getParentFolder

function Handler($context, $inputs) {
    $connection=Connect-VIServer -Server vcsa.vmwarecode.com -User administrator@vmwarecode.com -Password VMware123! -force
    $foldername=Get-Folder|?{$_.Parent -match "VRM"}|select Name
    $connremoved=Disconnect-VIServer -Server *  -Confirm:$false
    return $foldername.name
}

Lets look at Choose Sub Application VRO action.

function Handler($context, $inputs) {
   $connection=Connect-VIServer -Server vcsa.vmwarecode -User administrator@vmwarecode.com -Password VMware123! -force
   $as=$inputs.parentFolder
   $folder=Get-Folder|?{$_.Parent -match $as}|select Name
   $connremove= Disconnect-viserver -server * -confirm:$False
   $foldername=@()
   $foldername=$folder.Name
   return $foldername
}

VRO actions are completed here , lets jump tp custom form for folder.

Here is the configuration for Sub-Application field.

Caution: As this is lab environment ,Here we are entering the Username and Password inside the action .
It may conflict with security concern of your organization if any
.

How to remove machine from VRA which are stuck in provisioning status in VRA 8

Past I have written article where I showed how to remove the deployment from VRA if those are stuck here .
Recently I have come across the situation where we do not have deployment but machines are stuck Under Machine TAB in VRA.

This is what we see below is expected

Here is the screenshot where you see stuck in provisioning



To remove those machines which are stuck ,We can utilize the api to force delete those machines.

Along with deleting the stuck machines you can use same module for multiple things like below and take reference .

  • How to login to VRA 8
  • How to list total deployment
  • How to delete the deployment
  • How to list the Blueprint
  • How to release the blueprint
  • How to list the machines in VRA
  • How to delete the machines



We are covering above How to delete the machine in this article , for rest of the steps are attached in my previous blog.

No need to worry about if you are not from python background or do not know code, Just follow the below instruction and we are good .



  1. Please follow the detailed instruction Here python installation and required module before we use this module –Do not skip this step.
  2. Download the file from Above and unzip and copy the file by name VRA8 and paste the file in directory where python is installed
    general path in windows is : C:\Users\Administrator\AppData\Local\Programs\Python\Python39
  3. I am using Python 3.9 for example ,It will be different as per your version.
  4. Once the step 1-3 is completed , all we need to do is run the below commands.

from VRA8 import vraClass
as1 =vraClass(vrafqdn="vra82.vmwarecode.com", username="administrator", password="VMware123!")
as1.getMachines()

Once we get the ID from above getmachines , we will run the deleteMachine to remove the stuck machine from VRA.

as1.deleteMachine(id='89af5f50-cb28-40ac-8734-d4dcc265fb8c')

Once we get the response 202 , Go to browser and refresh the browser you will see the VM is no longer in list ,Also we run the getMachines once again.

Happy Learning , Feel free to share your queries and feedback on this .
